Dana Spicer 1410/SPL36 U-Joint (Greaseable) 5-1410X

The Dana Spicer 1410/SPL36 U-Joint (Greaseable) 5-1410X is engineered to deliver the long-lasting performance and durability that drivers and fleet operators have trusted for over a century. Its greaseable design allows for routine relubrication, extending service life and reducing the risk of premature wear. Precision-ground bearing surfaces and heat-treated bearing cups improve durability, while Spicer's strict OE-level manufacturing standards ensure you get the same quality part every time. When you see the Spicer name, you know you are buying the highest quality product available. Spicer universal joints are no exception. Dana manufactures a full line of Spicer universal joints that are engineered to ensure longer life for vehicles in a wide variety of applications, from light vehicles to commercial and off-highway.

Features:

• 1410/SPL36 U-Joint
• Greaseable Design
• Forged Journal Cross
• Premium Seal & Bearings
• Heat-Treated Bearing Cups
• Premium Viton Multi-Lip Sealing Package

Specifications:
Greaseable: No
Type: OSR Style
OEM: Mfg Spicer
OEM Series: 1410/SPL36
Bearing Cap Diameter (1): 1.188
Bearing Cap Diameter (2): 1.188
SR(1)Brng Cap to Brng Cap(OSR): 4.188
SR(2)Brng Cap to Brng Cap(OSR): 4.188
VMRS: 024002046
Bearing Cap Type: Round
Snap Ring Type: External
Snap Ring Included: Yes
Material: Steel
Mounting Hardware Included: No
Pre-Greased: Yes
Grease Zerk Included: Not Required
Hardware Included: No
Length A: 4.188"
Length B: 4.188"
Length A: 106.400mm
Length B: 106.400mm
Bearing Cap Type A: OSR
Bearing Cap Type B: OSR
Bearing Cap Diameter A: 30.175mm
Bearing Cap Diameter B: 30.175mm
Package Type: EACH
Package Qty: 1
