Diesel Site CFIK60 Coolant Filtration System

Protect the cooling system in your 2003-2007 Ford 6.0L Powerstroke with the Diesel Site CFIK60 Coolant Filtration System from XDP.  Most diesel engines use sand in the casting process that is generally not entirely removed. Over time, a lot of this sand seeps out of the casting and damages hoses, water pump seals, and radiators.Removal of this sand can greatly increase your water pump life. Diesel engine coolant also contains additives that are designed to protect the cylinders from cavitation erosion. As these chemicals are used, they change from a liguid to an organic / solid form. As the solids erode from the cylinder linings, they become an inert particle left behind floating around actually causing more damage, clogging coolers, wearing away seals, etc. This is called sediment fallout. Sediment fallout is very abrasive.

One additional benefit of the installation of the 6.0L coolant filter is the additional protection of the Oil Cooler and the EGR Cooler. The coolant passes through the oil cooler before it heads towards the EGR cooler. Often times the oil cooler can become clogged with debris from the cooling system. Without sufficient coolant passing through the EGR cooler, the EGR cooler can fail too. When the coolers fail, you must replace them.

Dieselsite custom CNC machined a tee to tap into the heater line. They did this so there was no extra weight hanging off the heater hose than necessary. This machined piece weighs only ounces. In addition to the machined fitting a custom stainless-steel mounting bracket has been designed specifically for easy bolt in on the 6.0 Ford. All clamps are 100% stainless steel as well, even the clamp screws.

The Dieselsite Coolant Filter Install Kit will remove the loose particles in your cooling system and give your water pumps, radiators, water necks and radiator hoses the protection they need from these abrasive materials.  Wear is virtually eliminated by the removal of undesirable elements in your system.

How Does It Work?

The Diesel Site Coolant Filter Kit is a bypass-style system that filters a small amount of the coolant on each pass. Using a spin on filter makes it easy for you to change your coolant filter at regular intervals.  These filters will remove all solid particles, new or old.  It is never too late to install a coolant filter in order to extend the longevity of your cooling system components.  While you cannot reverse the damage that is already done, you can eliminate further damage from occurring.  This kit is a must for every truck.

If you are one of the unlucky owners who have lost your pump between 40,000 and 80,000 miles, it isn't too late to protect your new pump.  While some damage to your pump may already be done, a coolant filter install kit will extend the longevity of your pump before it fails. It will help ensure that your next water pump will last much longer than your first one did. The Diesel Site CFIK60 Coolant Filtration System will give the protection your cooling systems need from these abrasive materials. This kit includes all fittings, hose, and stainless steel clamps needed for installation.

Features:

• High-Quality Hose
• Stainless Steel Clamps
• Custom Bracket & Fittings
• CNC-Machined Aluminum Filter Block
• Removes Any Solid Particles From The Coolant

Ball Valves can be added to aide in filter removal and installation.

Fits 2003-2007 Ford 6.0L Super Duty Trucks and 2003-2005 Ford 6.0L Excursion

Use one filter every three months for the first nine months after installation. After the 4th filter is installed your filter should be changed once per year.

The Donaldson P554685 filter can be substituted for the Baldwin B5134 that is included with the Diesel Site kit.
