Dorman 265-850F Transmission Filter And Gasket

The Dorman 265-850 8HP70/8HP75 Transmission Pan With Drain Plug (With Gasket & Bolts) provides a service-friendly upgrade for your Ram equipped with the 8HP70 or 8HP75. Routine transmission service on your 8HP70/8HP75 can be messy due to the design of the factory transmission pan, which must be lowered carefully to avoid spilling fluid. This Dorman OE FIX transmission oil pan is designed to match the fit and function of the original equipment pan but is manufactured with a handy drain plug to allow the trans fluid to be removed before service. This pan also features our convenient 265-850F replaceable filter design and filter kit that is engineered specifically for use with this product and includes a new filter, gasket and screws. Unlike the factory pan that lacks a serviceable filter, this unique upgrade can help reduce maintenance costs by enabling the replacement of just the clogged filter during transmission servicing.

Capacity: 8.8 qt

Color: Black

Configuration: One-Piece

Dipstick Port: No

Drain Plug Included: Yes

Drain Thread Diameter: 24 mm

Gasket Configuration: One-Piece

Gasket Or Seal Included: Yes

Grade Type: Standard Replacement

Length: 19 in

Material: Plastic

Maximum Depth: 2.2 in

Maximum Width: 11 in

Minimum Depth: 1 in

Mounting Hardware Included: Yes

Mounting Hole Diameter: 8 mm

Mounting Hole Quantity: 13

Package Contents: 1 Transmission Pan; 1 Filter; 1 Gasket, 6 Screws

Thickness: 2.5 mm

Width: 11 in
